Precision Linear Actuator Catalog / Piezo Motors, Servo Motors and Stepper Motors

04-01-2008 12:43 PM CET | Science & Education

Press release from: PI (Physik Instrumente) L.P. Piezo Nano Positioning

The linear actuator catalog can be downloaded at  http://www.linear-actuator.net

The linear actuator catalog can be downloaded at http://www.linear-actuator.net

PI's new catalog features sub-micron to sub-nanometer precise compact actuators driven by novel ceramic motors and classical motors.

Systems range from pen-tip-sized ceramic actuators for high-volume optics & medical applications, to high-force non-magnetic ceramic actuators for ultra-precision vacuum applications.

High-speed ultrasonic actuators provide velocity to 800 mm/sec (32 in/sec) and accelerations to 20g, while flexure actuators respond to control input in as little as a few 100 µsec to operate fast pumps or position optics in high-speed focusing or alignment applications.

In addition to the novel piezo ceramic motors and actuators, a number of ballscrew actuators with servo and stepper motors are also available; they provide resolution in the 0.1 micron range, and forces to 400 N (40kg / 88 lbs)

Non-magnetic and vacuum compatible versions are offered throughout the product spectrum. These precision actuators are designed for applications in fields such as:

* Semiconductor Metrology
* Medical Design
* Ultra-Precision Machining
* Aerospace & Astronomy
* Test & Measurement
* Photonics, Optics, Microscopy
* Biotechnology / Life Sciences
* Precision Motion Control

PDF Catalog Download
The catalog can be downloaded at
http://www.linear-actuator.net

PI (Physik Instrumente) L.P.
16 Albert St.
Auburn, MA
01501

USA / Canada (East):
Tel: (508) 832-3456
Fax: (508) 832-0506
Email: info@pi-usa.us

USA / Canada (West)
Tel: (949) 679-9191
Fax: (949) 679-9292
Email: info@pi-usa.us


Europe:
Germany: +49 (721) 4846-0
Italy: +39 (02) 665 011 01
France: +33 (1) 481 039 30
UK: +44 (1582) 764 334

Asia
Japan: +81 (6) 6304 5605
China +86 (21) 687 900 08

About PI
PI is the industry leader in ultra-precision motion control devices for nanoscale manufacturing, test and research applications. PI has been developing and manufacturing standard & custom precision linear actuators with piezoelectric and electromagnetic drives for 35+ years. The company has been ISO 9001 certified since 1994 and provides innovative, high-quality solutions for OEM and research. PI is present worldwide with eight subsidiaries and total staff of 450+. PI - Moving the NanoWorld.
