Press release
ProtoTech releases new version (v 1.4.0.0) of 3D Measure Up with mesh repair and measurements export features
Features of this release
1.Measurement Info tab:
User can view all Girths and Length Measurements under the single tab in the form of tree. Whether they are girths from Measuring Planes, or Straight lengths or ‘On Surface’ lengths, they are properly classified and represented in the tree. User can also perform following operations on them:
a. Hover on particular length to see its value
b. Show/hide one or all of them through check boxes
c. Delete any Length (just by right click and selecting delete option)
d. Rename any of the Length measurements
2.Mesh Manipulation/editing functionality:
Quite often, the final model (e.g. OBJ/STL) that a user gets after scanning,
a. Have gaps /holes (i.e. missing faces/triangles) in them
b. Can have stray entities or unwanted parts that are not of interest to the user.
Many factors can be responsible for these behaviors like noisy or lossy scans or low precision/quality of the scan.
These problems may have an impact on the accuracy of girth/length measurements done using ‘3D Measure Up‘, so these features have been added.
A] Have gaps/holes (i.e. missing faces/triangles) in them: User can use this feature to detect all the gaps /holes in the model and heal them.
B] Can have stray entities or unwanted parts that are not of interest to the user: User can use this feature to remove any unwanted disjoint entities form the model.
Removal of stray entities can be done in two ways:
Manual Selection: By manually selecting disjoint entities and pressing the delete button.
By Percentile: By choosing desired Percentile (that will automatically select all entities whose triangle count is below that percentile for deletion) and pressing OK.
3.Export Length/Girth Information in CSV:
User can use this feature to export all the girth and length information (as visible in Measure Info Tab) to a CSV file.
4.Save and load the project (*.3dmp file)
Now user can save the current project with all girths and lengths, and open this project by loading project file (*.3dmp) which was already saved by the user.
5.Object manipulator for modifying the plane
User can use object manipulator to do translations or rotations of measure body planes along X, Y or Z axis.
Why to use 3D Measure Up?
a. Allow the user to measure various dimensions on mesh files (Currently, OBJ and STL files are supported)
b. Allow the user to measure girths on the model at any location
c. Direct distance between any two points and on surface distance measurements are possible
d. This tool is very useful for Human body measurements
e. Some typical human body measurements are computed automatically on single click
f. Model can be aligned for more accurate measurements
g. Support Mesh cleanup and mesh healing functionalities
h. Export data as CSV
i. Save project and restore
j. Measure volume of entire model or the selected portion only
For more information on 3D Measure Up, please visit here:
https://bit.ly/2J7xNmv
About ProtoTech Solutions:
ProtoTech is a custom software solutions company with skills in
1. Development of 2D/3D based Engineering applications.
2. AR/VR Development.
3. 3D Desktop/Mobile/Web Visualization
4. Engineering File formats & Data Interoperability Mobile/Web Engineering Apps Development
5. Quality Assurance/Testing services.
For more information:
Contact us: info@ProtoTechSolutions.com
Visit us: www.prototechsolutions.com
ProtoTech Solutions is a software development and consulting company that specializes in rapid development of engineering software by providing fast, reliable and accurate solutions. PTS is a private firm composed of well-trained and experienced professionals who are fully committed to helping our customers accelerate their development programs and build advanced solutions.
“Rainbow Plaza”, Office No. 207,
2nd Floor, Shivar Chowk,
Rahatani, Pune. 411017. INDIA.
