Ceramic Polymer - Premium Coating „Proguard CN-1M“ – acid-proof at pH-value 2!

07-25-2014 07:02 PM CET | Industry, Real Estate & Construction

Press release from: Ceramic Polymer GmbH

Coating of concrete chamber for liquid pig feed, pH-value 2

Coating of concrete chamber for liquid pig feed, pH-value 2

The coating systems of Ceramic Polymer GmbH are applied for complex agricultural applications due to extreme chemical and abrasion resistances. The physical properties of the products are deciding for a durable value preservation of different buildings within agrarian economy.

Concrete and steel constructions of digesters, septic tanks, slurry reservoirs, fodder fermenting silos, biogas and composting plants as well as wastewater systems are constantly exposed to high chemical attack by acidic contents of the storage substances. Concrete erosions of 1 to 2 cm and extreme corrosion damages on all steel components are measured per year.

Recently, the company BBH Bocholter Bautenschutz Handel coated 3 concrete chambers for liquid pig feed with Ceramic Polymer’s premium coating Proguard CN-1M.

The excellent chemical resistance of this system provides permanent protection against acidic attack of the aggressive substance.

First of all, the concrete surfaces were accurately cleaned. Unevennesses and blowholes were leveled with concrete filler. Afterwards the area was grit blasted to prepare the concrete for the application of the coating.

The concrete walls and ceilings were coated directly with the coating product Proguard CN-1M. No previous use of a primer is necessary when the application is conducted by airless spraying methods. The first layers were applied in grey color and a thickness of 400 µm. After a waiting period of 3.5 hours the second layers were completed in black also with the same thickness.

Concrete floors can be coated easily with conventional application tools such as rake or roller. For leveling and sealing of the floor areas, the primer CP-Synthofloor BETA 8016 was applied on the blasted concrete. On the following day the premium coating Proguard CN-1M was applied in 2 layers. Due to the treatment with rake and a spiked roller a ventilated and nonporous surface was obtained. The coated areas are fully cured after 48 hours and chemically resistant after 7 days.

Pig feed – an extreme acid compound

Oftentimes, liquid pig feed contains specific, organic acid additives to ensure good quality of the substance and prevent the growth of microbes (most microbes die in an acid ambience with a pH-value of 2). Therefore, acid feed is very digestible for pigs. For instance, formic acid is used against salmonellae, is antibacterial effective and obviates diarrhea diseases. Propionic and sorbic acids act against fungal infections and citric acid improves the taste of the feed.

The Ceramic Polymer GmbH produces high-quality, solvent-free protective coatings for different kinds of industries. Due to the integration of microscopic ceramic and other special particles, coating systems with outstanding physical properties such as excellent chemical resistances, high temperature stabilities and extreme abrasion resistances are generated.
The Ceramic Polymer coatings are applied directly on the blasted substrate (e.g. steel, stainless steel, concrete) without the previous use of a primer. In this way extreme adhesion is achieved.
The scopes of the Ceramic Polymer coatings are for instance all kinds of storage tanks, pipelines or process vessels for the oil & gas industry as well as different maritime constructions, waste water or drinking water applications.

Ceramic Polymer GmbH
Stephanie Wuensch
Daimlerring 9
DE-32289 Roedinghausen / Germany
Phone: +49 (0)5223-96276-0
Email: swu@ceramic-polymer.de
Web: www.proguard-coatings.de
