Automated Inspection of Bonding Pads

04-21-2011 03:03 PM CET | Industry, Real Estate & Construction

Press release from: GOEPEL electronics Ltd.

OptiCon AOI systems

OptiCon AOI systems

GOEPEL electronics’ OptiCon AOI systems can now be utilised for automated inspection of bonding pads for solder splashes, deformations and any other impurities in the micrometer range. Meeting these test tasks, an additional camera module with a resolution of 3 µm is available in the AOI systems. An adaptive illumination system and particularly developed inspection functions enable highest fault detection at extremely low false-call rate.

The high-resolution camera system can be utilised parallel to the test modules for component and solder joint inspection in the stand-alone and inline OptiCon systems. That enables an effective inspection of both soldered components and bonding pads in one production run.

GOEPEL electronics’ OptiCon AOI systems, offered in various configuration versions, can be utilised in different PCB production areas, e.g. before or after the soldering process, as stand-alone and inline machines. The AOI systems are able to detect manufacturing faults, such as faulty solder joints and components as well as multi-pin or misplaced components. The OptiCon series systems were honoured with several industry awards, e.g. the “Best in Test Award” for OptiCon BasicLine and OptiCon TurboLine.

About GOEPEL electronic:
GOEPEL electronic is a technologically leading vendor of professional Automated Inspection systems (AOI/AXI). A network of branch offices, distributors and service partners ensures the global availability of the products as well as the support of several hundred system installations. Founded 1991 and headquartered in Jena, Germany, GOEPEL electronic employs currently about 170 employees and generated revenue of more than 21 Million Euro in 2010. GOEPEL electronic has continuously been ISO9001 certified since 1996 and has been honoured with TOP-JOB and TOP-100 awards for being one of the best medium-sized companies in Germany. GOEPEL electronic’s products won several awards in recent years and are used by the leading companies in telecommunication, automotive, space and avionics, industrial controls, medical technology, and other industries. Further information about the company and its products can be found on the internet at www.goepel.com.

GOEPEL electronics Ltd.
Unit 1A
The Old Granary
Westwick, Cambridge
CB24 3AR/UK

Phone +44-1223-858298
Fax +44-1223-257800
www.goepel.co.uk

Stefan Meissner
press@goepel.com
