Innovative Tech Company Relies on Influx Data Logger for Vehicle Data Collection

Rebel CT Compact Data Logger Captures Vehicle Parameters

Dearman is an innovative technology company developing zero-emission power and cooling solutions. At the heart of Dearman’s technology portfolio is an innovative piston engine powered by the rapid expansion of liquid nitrogen – the Dearman Engine. The Dearman Engine is the first engine to deliver efficient power and cooling from the expansion of a cryogen. Its first application is a zero-emission transport refrigeration system. Performance and durability in application testing is a vital part of its development, so it’s crucial for the company to see all relevant data and to be able to select specific channels for reporting and performance iteration comparisons. With this in mind Dearman turned to Influx Technology for a vehicle data collection solution. As a North American distributor of Influx, CAS DataLoggers presents this Case Study showing the business benefits.

Installation

Since May 2015, Influx’s Rebel CT iveVehicle Datalogger has enabled the Dearman team to remotely monitor the Dearman engine’s health parameters –e.g. pressure and temperature. Due to the compact size and robustness of the Rebel data loggers, they are uniquely suited for problem investigations in the field. The Rebel data logger can be confidently and discretely fitted to customer vehicles to investigate anomalies or performance.

Usage

Offering a complete solution for CANbus network and sensor data, the Rebel CT records any available CANbus parameter such as temperature, speed and diagnostic trouble codes, DTC’s. Setup is easy with no need to write complex scripts so users can start monitoring in minutes. For CANbus datalogger applications, the Rebel data loggers can be used to collect raw CAN messages in a ‘Listen Only’ mode. Additionally, any of the OBD data users require can be acquired without the need for other instrumentation.

The logger features up to 9 CAN bus inputs, a K-Line input, four digital I/O channels, and four analog input channels. This allows robust and reliable collection of data from several sources, without any user interaction, for extended periods. The Rebel CT is also equipped for USB communication and supports SDHC card data storage, with the SD card securely housed behind a flap panel. It is packaged in a robust IP68 enclosure and can be optionally equipped with GPS, accelerometer, WiFi, and 4G. Users can also opt for a 1kHz internal XYZ accelerometer (+/-16G max), a K-Box, and a dash display.

OEM Engineering Data Acquisition

The Rebel family of data loggers are also ideal for OEM vehicle and powertrain calibration engineering. The high-speed sampling rates acquire internal ECU parameters. Advanced protocols support CCP/xCP and UDS fast data acquisition making the Rebel an ideal tool to support engineering projects.

Benefits

The Influx Rebel CT continues to be an important part of Dearman’s remote monitoring process and vehicle data collection. Its Wifi and 3G/4G connectivity enable both the pioneering operator and the Dearman team to gauge the health and performance of the system remotely. Dearman’s CTO comments:

“The Influx Rebel CT continues to be an important part of our refrigerated transport application development program. Dearman is bringing zero-emission power and cooling technology to market in a compressed time frame, and the Influx Rebel CT has supported our intensive application performance and durability testing program with outstanding reliability.” –Nick Owen, Chief Technology Officer, Dearman

For more information on the Rebel CT Data Logger, more Influx Technology products, vehicle data collection or to find the ideal solution for your application-specific needs, contact a CAS DataLogger Application Specialist at (800) 956-4437 or visit www.dataloggerinc.com.

Computer Aided Solutions, LLC. dba CAS DataLoggers is a distributor of data loggers, paperless recorders and data acquisition equipment.

We have the industry’s most complete selection of data logging equipment, with hundreds of different models from more than 18 manufacturers. With data loggers from 1 to 300 channels we can record temperature, humidity, force/strain, pressure, flow, voltage, current, resistance, vibration and other digital signals, in connection with serial (RS-232/RS-485), CAN/OBD or SDI-12 devices. We sell directly to end users and also work through a network of distributors and resellers throughout the United States, Canada, Central and South America.
