In-System Emulation Technology VarioTAP® supports Analog Micro Controller from Analog Devices

07-01-2010 03:53 PM CET | Industry, Real Estate & Construction

Press release from: GOEPEL electronics Ltd.

In-System Emulation Technology VarioTAP® supports Analog

GOEPEL electronic, world-class vendor of JTAG/Boundary Scan solutions announces the development of model libraries for Precision Analog ADµC706x micro controllers from Analog Devices for support of GOEPEL electronic’s innovative emulation technology VarioTAP®.
VarioTAP® model libraries are structured modular with IP (Intellectual Property) functions and enable a complete fusion of Boundary Scan test and JTAG Emulation. On this basis on-chip Flash can be in-system programmed. Additionally, VarioTAP® supports interlaced Bus Emulation Tests (BET) and System Emulation Tests (SET) for enhanced JTAG/Boundary Scan functionality.

“In particular our customers in Industrial Control and Medicine Technology use the combination of precision ADC and performant processor integrated in the ADµC706x to implement high-performance smart sensor systems. Their problem of non available Boundary Scan inside the chips is now alternatively solved by our VarioTAP® technology”, says Thomas Wenzel, GOEPEL electronic’s managing director of the Boundary Scan Division. “Simultaneously, there are completely new test and programming strategies, such as the combination of dynamic emulation tests in interaction with external Boundary Scan I/O modules as well as the execution of high-speed Flash programming on a unique platform.”

The VarioTAP® IP Models, supporting the ADµC706x enable the processor supported on-chip Flash programming as well as numerous emulation test functions for the on-chip periphery via the control of the integrated ARM7TDMI™ core.
Initially, all communication interfaces and GPIO functions can be dynamically tested on board level without applying a specific firmware. Afterwards, the embedded flash can be programmed. The combined process lasts no longer than some seconds, whereby the TAP signals’ adaptive streaming technology enables the execution of emulation tests parallel or interactively to Boundary Scan tests. For fault coverage extension external Boundary Scan test channels, e.g. GOEPEL electronic’s CION Modules™ can be utilised.
There are also hardware and software options for Gang handling of up to eight parallel UUT to increase production throughput. Test and programming times can be considerably reduced.

In order to use VarioTAP®, the user does not need any specific background knowledge, additional development tools, or processor specific Pods, simplifying the handling and ensuring ease of use.
Through OEM cooperation with all leading vendors of In-Circuit-Testers (ICT), Manufacturing Defect Analyzers (MDA), Flying Probe Testers (FPT), and Functional Testers (FCT), these new capabilities are available immediately for production tests with such test equipment.

The new VarioTAP® IP Models are supported by the Boundary Scan software SYSTEM CASCON™ Version 4.5.3, in combination with Boundary Scan controllers of the SCANBOOSTER™ series and the SCANFLEX® hardware platform. The models are enabled by the software’s license manager just like any of its other features. SYSTEM CASCON™ is a professional JTAG/Boundary Scan development environment, developed by GOEPEL electronic, featuring currently more than 40 fully integrated ISP, test, and debug tools.
VarioTAP® can be utilised in connection with the hardware controllers of the low-cost SCANBOOSTER™ series as well as the SCANFLEX® platform.
