Underhood Thermal Management & Engine Cooling Analysis

Delphin Data 64 KTM Temperature Measurement System
Malaysian automobile manufacturer Proton needed to test the underhood thermal management and engine cooling performance in their new manual 5-speed Proton Persona 1.6 M/T Line. The thermal test program was designed to check underhood part performance in order to ensure that the parts were working within design requirements after being exposed to high temperatures during driving and climbing. Engine cooling analysis testing was performed to verify cooling performance under various types of driving patterns including high-speed runs, idling, and hot soak and dead soak. To collect enough temperature data to get a complete picture of the Persona’s thermal distribution and engine cooldown, Proton’s automotive engineers needed a high-performance, flexible data acquisition device for use in their test setups which supported large numbers of channels and was able to connect to the very broad range of thermocouple types the program would use.

Installation
The Proton plant installed four Delphin Data 64 KTM Temperature Measurement Systems in its test chamber and in the trunk of the test car, with three of the units acting as slaves to increase the number of channels available to the master. These compact measurement systems were protected within industrial-grade 19-inch rack enclosures, with 250 of their 256 available channels used for the thermal management tests. During engine cooling analysis testing, the KTM devices were used to measure the temperature of the engine cooling system, (radiator and water temperature in a water jacket), the pressure of the test car’s A/C system, and engine revolution (RPM), requiring about 85 input channels.

A portable, all-inclusive device for multi-channel temperature measurement, the Delphin 64-KTM data acquisition system featured 64 channels of thermocouple inputs of every type including types E,J,K,L,N,S,R,T,U–providing plant engineers with a great deal of flexibility for high-precision, 24-bit resolution temperature measurements and achieved, depending on thermocouple and measurement area, an absolute accuracy of < 0.2 K. The modular design enabled the other 64-KTM units to be slaved to a master by simply connecting the additional devices, increasing capacity to over 250 measurement channels.

Usage
The 64-KTM devices performed stand-alone data logging and recorded the test data with a partitionable 1 GB internal memory storing up to 128 million data records. The memory’s independent data recording capability provided data security for long-term measurement runs. Integrated engine speed pulse measurement (rpm) was featured, as well as high and low pressure using strain gage pressure transducers. The sophisticated 64-KTM systems offered many features to ensure high-accuracy measurements, including differential inputs with 110V isolation and galvanic isolation to prevent measurement errors from ground loops. Inbuilt filters for 50Hz or 60Hz networks suppressed any power source interference, Measurement scaling was provided as required.

An Ethernet interface allowed easy integration for underhood thermal management into the plant’s network. Convenient data evaluation was then made available at any PC workstation in the plant. The 64-KTM also had interfaces for Modbus and Proton engineers set up many of the channels for limit values, calculations and event processing. These channels enabled the computation of characteristic values during measurement runs, and also included the calculation of moving averages and enabled monitoring and alarm functions. The master system was able to transmit e-mails or indicate limit value violations within an alarm table.

Live data analysis and post-processing was provided with the user-friendly ProfiSignal Basic evaluation software. Plant engineers appreciated its intuitive configuration and also utilized ProfiSignal for measurement data archiving and online/offline measurement data analysis.
Benefits
The Proton plant’s test programs benefited in several ways from installing the four Delphin data 64 KTM temperature measurement systems, the most immediate of which was the large number of channels available for the auto plant’s demanding test applications. The devices’ universal thermocouple connectors were easy to use and enabled quick and simple attachment of the many different types of thermocouples used in testing, with each measurement made at a high resolution and accuracy. The Ethernet interface increased data accessibility, while the ProfiSignal configuration software was an intuitive tool for plant engineers to archive, evaluate, and analyze the test data.

For further information on Delphin data acquisition systems and data loggers, underhood thermal management, or to find the ideal solution for your application-specific needs, contact a CAS Data Logger Application Specialist at (800) 956-4437 or visit www.dataloggerinc.com.
