Technical requirements for high acceleration life test (HALT) and high acceleration stress screening (HASS)(HALT & HASS Chamber)

1.The environmental stress applied in the HALT test varies in an increasing form. The test process is to trigger various latent defects in the product design by applying continuously increasing stress until the product reaches its failure limit.
2. HALT testing is carried out beyond the specified limits and has a very high testing efficiency.
3. The failure modes that occur during the HALT process are triggered under environmental stresses far exceeding the design specifications. However, these failure modes are all failure forms that occur in actual field use; otherwise, the HALT test would be invalid.
Temperature, humidity and mechanical stress
Temperature range: -170°C (liquid nitrogen assisted) to +200°C (silicon carbide rod heating), temperature variation rate ≥70°C/min (HALT) and ≥50°C/min (HASS), supports multi-stress synchronous loading (temperature + humidity + six-axis vibration).
Vibration magnitude: HALT should cover random vibrations of 30 to 100 GRMS (10 to 5000Hz), and during the HASS screening stage, it should be optimized to 20 to 60Grms to avoid overstress damage.
Composite stress
Electrical stress injection: Integrated 0~1000V DC power supply, simulating the voltage fluctuation of the equipment under extreme temperature and vibration environments (transient interference test of on-board ECU power supply).
Pneumatic coupling: Optional vacuum (10−2Pa) or high-pressure (2MPa) modules for high-altitude pressure loss of aerospace devices and high-pressure verification of deep-sea equipment.If you need more information about the models of our testing equipment. Please contact me.https://www.chamber-testing.com/

Guangdong Test EQ Equipment co., Ltd.
Address : TESTEQ Science and Technology Park, No. 5, Wenzhou Road, Dongcheng Sub-district, Dongguan City, Guangdong Province, China
WhatsApp: +8613310826672
Tel: +86-0769-85914911
Web: www.chamber-testing.com
E-mail: Kris@test-eq.com

Headquartered in the Pearl River Delta Industrial Zone of Guangdong, TESTEQ stands as a leading innovator in advanced environmental testing equipment R&D and manufacturing. Our cutting-edge technologies and scientific achievements have consistently fueled China's technological advancement, specializing in tailored environmental simulation testing systems for research institutions and scientific organizations worldwide.
