ASTM A333 Seamless Low Temperature Steel Pipe

Product introduction ASTM A333 is the standard specification given to all the welded as well as seamless steel, carbon and alloy pipes which are intended to be used at places of low temperatures. The ASTM A333 pipes are used as heat exchanger pipes and pressure vessel pipes.

As it was stated in the above section, that these pipes are used in the areas where temperature is extremely low, they are used in large ice cream industries, chemical industries and other such places. They are used as transportation pipes and are categorized into different grades. The classification of grades of these pipes is done on different factors like temperature resistance, tensile strength, yielding strength and chemical compositions. The ASTM A333 pipes are furnished into nine different grades which are designated by the following numbers:1,3,4,6.7,8,9,10, and 11.

Product Details

Specification
ASTM A333/ASME SA333

Type
Hot Rolled/Cold Drawn

Outer Diameter Size
1/4NB TO 30NB(Nominal Bore Size)

Wall Thickness
schedule 20 To Schedule XXS(Heavier On Request) Up to 250 mm Thickness

Length
5 To 7 Meters,09 To 13 Meters, Single Random Length, Double Random Length And Customize Size.

Pipe Ends
Plain Ends/Beveled Ends/threaded Ends/Coupling

Surface Coating
Epoxy Coating/Colour Paint Coating/3LPE Coating.

Delivery Conditions
As Rolled. Normalizing Rolled, Thermomechanical Rolled /Formed, Normalizing Formed, Normalized and Tempered/Quenched andTempered-BR/N/Q/T

These pipes have an NPS 2to 36. Though different grades have different temperature strike test the average temperature that these pipes can stand is from-45 degree C, to-195 degree C. The ASTM A333 pipes must be made with the seamless or welding process where there must be no filler in the metal during the welding process.

ASTM A333 standard covers wall seamless and welded carbon and alloy steel pipe intended for use at low temperatures. ASTM A333 alloy pipe shall be made by the seamless or welding process with the addition of no filler metal in the welding operation. All seamless and welded pipes shall be treated to control their microstructure. Tensile tests, impact tests, hydrostatic tests, and nondestructive electric tests shall be made in accordance to specified requirements. Some product sizes may not be available under this specification because heavier wall thicknesses have an adverse affect on low-temperature impact properties.

ASTM A333 steel pipe production includes a series of visual surface imperfections to guarantee that they have been properly manufactured. ASTM A333 steel pipe shall be subject to rejection if surface imperfections acceptable are not scattered, but appear over a large area in excess of what is considered a workmanlike finish. The finished pipe shall be reasonably straight.

Technical data

Chemical Requirements

C(max)
Mn
P(max)
S(max)
Si
Ni

Grade 1
0.03
0.40 - 1.06
0.025
0.025

Grade 3
0.19
0.31 - 0.64
0.025
0.025
0.18 - 0.37
3.18 - 3.82

Grade 6
0.3
0.29 - 1.06
0.025
0.025
0.10 (min)

Yield and Tensile Strength

ASTM A333 Grade 1

Minimum Yield
30,000 PSI

Minimum Tensile
55,000 PSI

ASTM A333 Grade 3

Minimum Yield
35,000 PSI

Minimum Tensile
65,000 PSI

ASTM A333 Grade 6

Minimum Yield
35,000 PSI

Minimum Tensile
60,000 PSI

Jiangsu Hangdong Metal Products Co., Ltd. is a subsidiary of Jiangsu Hangdong Iron & Steel Group Co., LTD. Is a research and development, production, sales, service in one of the professional metal material production enterprises. 10 production lines. The headquarters is located in Wuxi City, Jiangsu Province in line with the development concept of "quality conquers the world, service achievements the future". We are committed to strict quality control and considerate service. After more than ten years of construction and development, we have become a professional integrated metal material production enterprise.
