Connectors for Bus- and Train applications

07-09-2014 07:01 PM CET | Industry, Real Estate & Construction

Press release from: ESCHA Bauelemente GmbH

Wall installations, overmolded and field wireable wiring solutions as well as reflow-capable flanges.

Wall installations, overmolded and field wireable wiring solutions as well as reflow-capable flanges.

Halver, 9 July 2014 – The German Connector- and Housing specialist ESCHA has developed a completely new product program consequently oriented to the typical requirements of the Bus- and Train manufacturers. The connectivity components will make their public premiere at the international trade show Innotrans in Berlin from 23-26 September 2014 and will eventually be available immediately.

Reliable on-board network systems have evolved into a decisive factor within the vehicle development on modern busses and trains. Efficient and resistant networks provide for safety and passenger comfort. Complex subsystems (IEC 61375-3-4) supply the main server with real-time information via a high-performance base network (Backbone according to IEC 61375-2-5) and are, meanwhile, a necessary requirement for the transnational European train traffic.

The new ESCHA product program for Bus- and Train applications is oriented to the typical requirements of these modern board networks: The components can be swiftly and easily integrated into the vehicle; they provide for a safe and reliable data transmission up to 10 Gbit/s according to Cat6A and also meet the relevant fire protection standard DIN EN 45545 (Hazardous Level 3) as well as DIN EN 50155 for all electronic facilities being installed on train vehicles.

At market launch end of September 2014, 4-pole and 8-pole Ethernet M12x1 connection- and junction cables in overmolded- as well as field-wireable versions will be available. Moreover, relevant reflow-capable flanges for device connectivity (e.g. switches) as well as a cable connectos for lossless cable extensions will be provided. The overmolded connectors are equipped with a high-grade Railcat-cable optimally resistant to the harsh environmental conditions and mechanical, chemical or thermal stresses on trains.

360°-Shielding indispensable

All connectors and flanges of the new product line have a continuous 360°-Shielding. This is based on own-developed and patented ESCHA 2SSK-Technology, providing for a permanent shielding even with vibration and high mechanical stresses. The shield connection is effected through a reliable crimping with the shield housing. The final two-component overmolding is the only solution currently available on the market meeting protection classes IP67, IP68 and IP69K requirements irrespectively of the used calbe jacket.

The aforementioned products will make their trade-show premiere at the Innotrans Berlin in Hall 10.1; stand 312 from 23-26 September 2014.

ESCHA - About us

The ESCHA Group is a leading supplier in the fields of connectivity and housing technology. For more than 30 years, the family-controlled company has been developing and manufacturing innovative product novelties taking dynamics to the market for automation components. Based on its standard products, the company designs custom-made connectivity and individual special solutions. With more than 400 employees and highly in-depth development and production, ESCHA is extending its product portfolio constantly and independently. ESCHA guarantees high availability and consistent quality of its products worldwide through production facilities in Germany, Czech Republic and China as well as licensed production in USA and Mexico.

ESCHA Bauelemente GmbH
Elberfelder Straße 32
58553 Halver
Germany
www.escha.net/MEN/en/default.htm

Dipl.-Medienökonom Florian Schnell
Public Relations Management
Tel. +49 2353 708-156
E-Mail: f.schnell@escha.net
www.escha.net/MEN/en/Press_Room.htm
