transfluid® present new, economical ways for tube bending up to tube cleaning machines on HANNOVER MESSE 2011

tube processing in hydraulics - the efficiency of special by transfluid®

Special solutions are always in demand when special requirements must be met, such as in tubing systems for hydraulics. Bends are allowed here ovalized only slightly and tubes are usually manufactured in small batches. Accurate fit ensures safe, leak-free sealing systems and optimal cleanness ensures functioning whole system. Manufacturer's instructions for connecting systems have to be followed exact. New, cost-effective solutions for these challenges presents the transfluid®Maschinenbau GmbH from 04 to 08 April on this year's HANNOVER MESSE.

The specially developed software t control provides transfluid® best conditions for efficient tube processing. The customized software allows you to import coordinates and process data directly from the respective CAD program online and start the process.

In the teamwork with the quick-changing-system for tooling transfluid® bending machines (t bend) allow short tool changing times in the lower one-digit minute area. Besides, the excessive lengths which are needed, for example to be able to attach an end forming at the pipe are automatically considered. From the outset gross contamination is avoided in the system and cuttings are made up to a pipe diameter of 30 mm exactly and chipless.

The further procedure depends on the choice of the particular connection system. If cutting rings are used they can be mounted easily while the CNC bending machine bends the following tube. The transfluid® cutting ring pre-assembly machines are constructed so compact that all bending geometries can be processed.

"If as a connection system tube end formings are used, it makes sense to start with forming on both sides of the straight tubes before the bending process. That means first forming and then bending, "explained transfluid® Managing Director Gerd Nöker. Here transfluid® see significant benefits, because these end forming machines are usually less compact and require longer clamping area. "When forming first for the forming machines clamping jaws without saw teeth can be used. The coating of the tubes will not be damaged in this way, "said Gerd Nöker.

The difference of the bending machines is in the drives. In general, servo-electric or hydraulic drives are used. transfluid® also offers a special feature: power-controlled variable-speed hydraulic drives. Here constant pumps are used in conjunction with variable speed motors. The volume flow can be adjusted for each cylinder. This reduces the energy consumption, the hydraulic dissipated power, which is introduced into the oil, and the noise level dramatically. This type of drive is highly efficient and reduces life cycle costs significantly.

To be able to bend already formed tubes as well as straight tubes, the bending tools for transfluid® bending machines are equipped with a double clamping system, for the collets as well as for the bending tools. With this they are able according to demand to take up either formed tubes, or the straight parts. For the end of the tube processing cleaning systems (t clean) takes care for the final tube cleaning and secures the required demands for optimum cleanness.

Visitors of the HANNOVER MESSE can see the solutions of the Global Player from Schmallenberg in hall 20 stand D 19. transfluid® presents for various requirements the solution for tubes.

transfluid® Maschinenbau GmbH – the solution for tubes

Since 1988 transfluid® continually improved technologies in tube processing to meet customers’ demands, offering optimum, tailor-made solutions in machine and plant construction, that are used in the automobile, ship building and furniture industries as well as the construction of railings and conveyor technology. The Schmallenberg-based company has become a global brand with service offices in Europe and Asia.

transfluid®’s product portfolio offers perfect solutions in five different machine categories, that meet all the requirements in tube processing. t bend includes semi- and fully-automatic tube bending machines as well as large-diameter tube bending machines.. t form represents high-quality axial, rolling and combined tube forming machines. Automation systems with sophisticated concepts for bending and forming technology belong to the t motion category. With t cut, transfluid® offers tube cutting machines in different system variants und t clean is transfluid®’s range of tube cleaning machines for guaranteed cleanliness of work pieces and pipes.
