Fast 3d-modelling for acoustic prediction
SketchUp is a very intuitive and yet powerful 3D-modeling software, developed for architectural sketches. The properties and functions of SketchUp make it predestined to model rooms also for acoustic prediction software such as CATT-Acoustic, EASE, Odeon and similar software. Sketchup supports the user in building consistent models which meet the requirements of acoustic models.
Rahe-Kraft, an acoustic consultancy based in Berlin, Germany, has developed a Plug-In for SketchUp which exports even complex models to native CATT-Acoustic syntax. The plugin called SU²CATT was originally designed for in-house use for Rahe-Kraft and is now distributed commercially.
Besides the geometry, the plugin supports straight-forward visual assignment of material properties, layer-based modelling and a number of CATT-Acoustic-specific geoetry and modelling tags such as double-sided planes and more.
A fully-functional Demo-verson is available for download, the only restriction is a maximum number of 100 planes which will be exported. This is sufficient for smaller projects, commercial use of the demo is explicity allowed. SU²CATT runs with both the commercial and the free version of Sketchup 6.
The full version of SU²CATT 1.0 is now available for € 249 ($325 in U.S.) for a branch office license.
Info, Download and Support for SU²CATT: www.rahe-kraft.de
Info and Download SketchUp: www.sketchup.com
Rahe-Kraft is an acoustic consultants office, specialized in electroacoustic systems, located in Berlin - Germany. Rahe-Kraft is founded in 2001 and managed by Jakob Kraft and Peter Rahe. The office is focused on design, measurement, optimising and servicing public adress systems in any kind of acoustic environment. Rahe-Kraft is operating worldwide.
Rahe-Kraft GbR
Acoustic Consultants
Mr. Peter Rahe
Moeckernstr. 26
10963 Berlin -Germany-
Tel. +49-30-2639369-0
Fax. +49-30-2639369-20
peter@rahe-kraft.de
www.rahe-kraft.de
