CO-NELE UHPC Mixer | High Performance Planetary Mixer for UHPC

CO-NELE is a benchmark brand in the field of UHPC mixers. Its CMP Vertical Shaft Planetary Mixer [https://www.conele-mixer.com/uhpc-concrete-mixer-2.html] is specially designed for the high homogeneity, high shear force and high wear resistance requirements of UHPC, making it a mainstream choice for global UHPC production.

Image: https://www.conele-mixer.com/uploads/Planetary-Mixers-type-CMP.jpg

Core Advantages of CO-NELE UHPC Mixers [https://www.conele-mixer.com/concrete-planetary-mixer-details.html] (Ideal for UHPC Applications)

1. Mixing Performance: Perfectly Matches UHPC Characteristics

* Planetary + High-Speed Shear Composite Motion: The mixing arm rotates both revolution and rotation, equipped with high-speed fly cutters, achieving 360 degrees full coverage without dead corners in 5 seconds, solving the problems of agglomeration of ultra-fine UHPC powders and steel fiber clumping.
* Ultra-High Homogeneity: Uniformity CV less than or equal to 0.05, fiber dispersion rate >98%, with a single batch mixing time of only 3-8 minutes, far more efficient than traditional models.
* Patented Mixing Structure: Parallelogram blades (patented) can be reused after 180 degrees flipping, doubling the service life.

2. Durability: Resists High Abrasion of UHPC

* High Wear-Resistant Materials: Mixing pot/liner made of high-chromium alloy/AR500-grade wear-resistant steel, blades/arms adopt hardened alloy with replaceable wear heads, thickness greater than or equal to 20mm.
* Heavy-Duty Transmission: Self-developed hard-tooth surface planetary reducer (patented) features high torque, low noise and long service life, suitable for continuous high-load UHPC production.
* Reliable Sealing: Top-mounted drive + multiple sealing systems ensure zero slurry leakage, adapting to the low water-binder ratio of UHPC.

3. Intelligence & Adaptability: Meets Scaled & Customized Production

* PLC Intelligent Control: Touch-screen operation, formula storage, precise metering (error plus-minus 0.5%), fault diagnosis, ensuring stable UHPC production.
* Flexible Discharge: 1-3 hydraulic/pneumatic discharge doors for fast discharging and no residue, adapting to different production line layouts.
* Full Series Coverage: Ranging from 50L for laboratories to 6000L for large-scale production, supporting fixed/mobile/fast-moving mixing plants for precast, bridge, wind power and other scenarios.

4. Service & Reputation: Long-Term Reliability

* Over 100 patents, independent core technologies, in line with German standards.
* National service network providing one-stop support for installation, training, spare parts and after-sales service.
* Verified by long-term projects: e.g., Weihai UHPC decorative panel project, CMP1500/2000 models running stably for 7 years with outstanding service life and cost performance.

Main CO-NELE UHPC Models (CMP Series)

MODEL
DISCHARGE CAPACITY (L)
MIXING POWER (KW)
APPLICATION SCENARIOS
TYPICAL OUTPUT

CMP50
50
3
Laboratory, pilot test, R&D
1-3 batches/hour

CMP250
250
15
Small precast, sample production
4-6 batches/hour

CMP500
500
22
Medium precast, component factory
6-8 batches/hour

CMP1000
1000
37
Conventional UHPC precast, bridges
8-10 batches/hour

CMP1500
1500
55
Large precast, municipal engineering
10-12 batches/hour

CMP2000
2000
75
Large-scale production, wind turbine towers
12-15 batches/hour

CMP3000
3000
110
Extra-large scale, precast bases
15-18 batches/hour

CMP4500
4500
250
Mega projects, continuous production
18-22 batches/hour

Selection Solutions by Scenario

1. Laboratory / R&D

Small Batch, High Precision

Recommended: CMP50 / CMP100

Compact size, easy operation, ideal for UHPC formula R&D and performance testing.

Optional vacuum mixing for preparing high-density UHPC samples.

2. Small & Medium Precast Plants

Components, Panels, Decorative Parts

Recommended: CMP500 / CMP750 / CMP1000

Balances efficiency and cost, 1000L per batch suitable for most precast components.

Can be equipped with a simple batching station to quickly build a UHPC production line.

3. Large Precast / Bridges / Wind Power

Large Scale, High Strength

Recommended: CMP1500 / CMP2000 / CMP3000

Heavy-duty design for steel fiber UHPC and large-volume components.

Adaptable to UHPC fast-moving mixing plants for multi-site mobile construction.

4. Mega Projects / Continuous Production

Ultra-High Output

Recommended: CMP4500 / CMP6000

Extra-large capacity and high power to meet 100-ton daily UHPC production.

Fully automatic batching + intelligent control, compatible with Industry 4.0 production lines.
