Revolutionizing Automotive Electronics: Unveiling the Power of STMicroelectronics VN9D30Q100FTR

The VN9D30Q100FTR is a MOSFET and Power Driver optimized for extreme low voltage operation, high-speed switching, and advanced diagnostic capabilities. It provides excellent performance for controlling resistive, capacitive, and inductive loads in automotive applications.

STMicroelectronics VN9D30Q100FTR's Features

*
AEC-Q100 qualified: Ensures compliance with automotive industry standards for quality and reliability.

*
General features: Extreme low voltage operation for deep cold cranking applications (compliant with LV124, revision 2013), 24-bit ST-SPI for full diagnostic and digital current sense feedback, integrated 10-bit ADC for digital current sense, integrated PWM engine with independent phase shift and frequency generation (for each channel), programmable Bulb/LED mode for all channels, advanced limp home functions for robust fail-safe system, very low standby current, optimized electromagnetic emissions, very low electromagnetic susceptibility, control through direct inputs and / or SPI, compliant with European directive 2002/95/EC.

*
Diagnostic functions: Digital proportional load current sense, synchronous diagnostic of over load and short to GND, output shorted to VCC and OFF-state open-load, programmable case overtemperature warning.

*
Protection: Two levels load current limitation, self limiting of fast thermal transients, undervoltage shutdown, overvoltage clamp, latch-off or programmable time limited auto restart (power limitation and overtemperature shutdown), load dump protected, protection against loss of ground.

STMicroelectronics VN9D30Q100FTR's Attributes

TYPE
DESCRIPTION

Category
Integrated Circuits (ICs) [https://www.sic-components.com/integrated-circuits-ics]Power Management (PMIC) [https://www.sic-components.com/integrated-circuits-ics/power-management-pmic]Power Distribution [https://www.sic-components.com/integrated-circuits-ics/power-management-pmic/power-distribution-switches-load-drivers]Switches, Load Drivers

Mfr
STMicroelectronics

Series
-

Packaging
Tape & Reel (TR)Cut Tape (CT)

Part Status
Active

Switch Type
General Purpose

Number of Outputs
6

Ratio - Input: Output
1:6

Output Configuration
High Side

Output Type
N-Channel

Interface
SPI

Voltage - Load
4V ~ 29V

Voltage - Supply (Vcc/Vdd)
2.7V ~ 5.5V

Current - Output (Max)
6.6A

Rds On (Typ)
90mOhm

Input Type
Non-Inverting

Features
Status Flag

Fault Protection
Current Limiting (Fixed), Over Temperature, Over Voltage

Operating Temperature
-40 degrees C ~ 150 degrees C (TJ)

Mounting Type
Surface Mount, Wettable Flank

Supplier Device Package
32-QFN (6x6)

Package / Case
32-PowerVFQFN

Base Product Number
VN9D30Q100

STMicroelectronics VN9D30Q100FTR's Datasheet [https://datasheet.sic-components.com/vn9d30q100f.pdf]

STMicroelectronics VN9D30Q100FTR's Category - Power ManagemenPMIC)

Power Management Integrated Circuits (PMIC) are a type of integrated circuits specifically used for managing and controlling power in electronic devices. Their main functions are to ensure that all components in electronic devices operate at the correct voltage and current levels while improving energy efficiency, reducing power consumption, extending battery life, and in some cases providing power conversion and distribution.

Manufacturer of VN9D30Q100FTR - STMicroelectronics

STMicroelectronics is a global independent semiconductor company and is a leader in developing and delivering semiconductor solutions across the spectrum of microelectronics applications. An unrivaled combination of silicon and system expertise, manufacturing strength, Intellectual Property (IP) portfolio, and strategic partners positions the Company at the forefront of System-on-Chip (SoC) technology and its products play a key role in enabling today's convergence trends.
