NA EV DCFC Wall Mouted 40kW 60kW Dual Port with Touch Screen

The Dual Port DC Charging station [https://www.topstarevc.com/] is equipped with a 7-inch LCD touch screen and fast charging capabilities, enabling efficient and rapid charging of electric vehicles. It conforms to the OCPP1.6J, ISO15118, and CTEP standards.

* Input Voltage: 480V+10% 50-60Hz
* Output Power: 40kW, 50kW, 60kW
* Output Voltage: 200-1000V
* LCD Display: 7" screen
* Certification: ETL, FCC, Energy Star compliance
* Standards: OCPP1.6J, ISO15118, CTEP

Description

Introducing the Dual Port DC Charging Station [https://www.topstarevc.com/na-dual-port-40-60kw-dc-ev-charger-product/], the ultimate solution for efficient and rapid charging of electric vehicles. This cutting-edge charging station is designed to meet the growing demand for fast and reliable charging infrastructure, making it an essential addition to any electric vehicle charging network.

Equipped with a 7-inch LCD touch screen, the Dual Port DC Charging Station offers a user-friendly interface that provides real-time charging information and allows for easy operation. This intuitive touch screen interface enhances the overall user experience, making it convenient for both electric vehicle owners and charging station operators.

One of the key features of the Dual Port DC Charging Station is its fast charge capabilities. With the ability to deliver high-power charging, this station significantly reduces the charging time for electric vehicles, making it an ideal choice for busy urban areas, highways, and commercial locations where quick turnaround times are essential.

In addition to its fast charge capabilities, the Dual Port DC Charging Station is designed to comply with industry standards, including OCPP1.6J, ISO15118, and CTEP. This ensures seamless integration with existing charging infrastructure and enables interoperability with a wide range of electric vehicles, making it a versatile and future-proof solution for electric vehicle charging needs.

The Dual Port DC Charging Station [https://www.topstarevc.com/na-dual-port-40-60kw-dc-ev-charger-product/]is not only a reliable and efficient charging solution but also a sustainable one. By promoting the adoption of electric vehicles and reducing reliance on traditional fossil fuels, this charging station plays a crucial role in advancing the transition to a cleaner and more sustainable transportation ecosystem.

Whether you are a charging station operator looking to enhance your network or an electric vehicle owner in need of a fast and reliable charging solution, the Dual Port DC Charging Station is the perfect choice. With its advanced features, compliance with industry standards, and commitment to sustainability, this charging station sets a new standard for electric vehicle charging infrastructure.

Parameter Information

Electrical Characteristics
Input Voltage
480V+10%

Input Operating Frequency
50~60 Hz

Input Power Factor
>0.98 (Rated voltage input, above 50% load)

Output Power
40kW
50kW
60kW

Output Voltage
200-1000V

Max single output current
125A
150A
150A

Efficiency (Full Load)
greater than or equal to 95.5%

Environmental Parameter
Operating Temperature
-22 degrees F to 122 degrees F (-30 degrees C to 50 degrees C )

Operating Humidity
2095RH%; No condensation

Cooling Method
Forced air cooling

Storage Environment

Storage Temperature

-40 degrees F to 167 degrees F (-40 degrees C to 75 degrees C )

Storage Temperature

595RH%25RH%No condensation

Dimensions
(Height*Width*Thickness)
33in x23.6in x 14.4in (840mm x600m x 365mm)

Charge Port
16.4FT(5m)

Weight

almost equal to 220LBs (100kg)
almost equal to 231LBs (105kg)
almost equal to 231LBs (105kg)

Protection and Certification

Standards
NEC625,UL2202,UL2231,ISO15118,OCPP1.6J,CTEP compliance

Certification
ETL, FCC ,Energy Star compliance

Optional
RFID,4G,Color customization

Features

Fast Charge

Environmental Friendly

Modularized design, convenient to expand and maintain
