Safety performances and features of the C16-03 EV Charger cable

F32-03 EV Charger Cable [https://www.xuwentech.com/en-16a-3-phase-ac-charging-cable-on-vehicle-side-product/] Information

Product model

C16-03 EV Charger cable

Safety performance and feature of the product:

Rated voltage

250V/480V AC

Rated current

16A Max

Working temperature

-40 degrees C ~ +85 degrees C

Protection level

IP55

Fire-protection Rating

UL94 V-0

Standard adopted

IEC 62196-2

Safety performances and features of the C16-03 EV Charger cable [https://www.xuwentech.com/en-16a-3-phase-ac-charging-cable-on-vehicle-side-product/]

1. Comply with: IEC 62196-2 certification standard requirements.

2. The plug uses the one-piece design of small waist, which is advanced in appearance, grand, neat and beautiful. The hand-held design conforms to the ergonomics principle, having the anti-skid touch and comfortable grip.

3. Excellent protection performance, the protection grade reaches IP55

4. Reliable material: inflaming retarding, environmental protection, wear resistance, rolling resistance (2T), high temperature resistance, low temperature resistance, impact resistance, high oil resistance, UV resistance.

5.The cable is made of 99.99% oxygen-free copper rod with the best electrical conductivity. The sheath is made of TPU material, which can withstand high temperature up to 105 degrees C and is inflaming retarding, abrasion resistant and bending resistant. The unique cable design can prevent the cable from breaking core, winding and knot.

F.A.Qs

Q: Will there be battery leakage when charging in rainy days?

A: The part of the charging gun connected to the car is IP67 waterproof. It can continue to charge in heavy rain, but the side connected to 220V cannot come into contact with water.

Q: How long is the line?

A: The normal size is 5 meters, 10 meters, 15 meters. You can also customize the size, but it will take 2-3 days.

Q: How thick is the wire of the charging gun?

A: The charging gun uses the national standard 3*4 square copper core cable.
