What is Split Core Current Transformer? Industry Trends and Best Practices

A Split-Core Current Transformer is a type of current sensing device with a unique separable core design. Its core can be opened and closed like a "clamp," allowing it to be directly attached around an existing conductor without disconnecting the circuit. This enables non-invasive installation.

Unlike traditional current transformers (CTs) that require conductors to be threaded through a solid core (necessitating power shutdown and cable disassembly), split-core CTs can be clamped onto live cables without interrupting service. This design significantly enhances installation flexibility and safety.

Image: https://ecdn6.globalso.com/upload/p/653/image_other/2026-02/product-introduction-1.png

How It Works

Split-core CTs operate on the principle of electromagnetic induction:

*
When a current-carrying conductor passes through the core (or is placed within its opening), the alternating magnetic field generated around the conductor induces magnetic flux in the core.

*
The secondary winding wrapped around the core senses changes in magnetic flux and produces a proportional secondary current (typically standardized to 5A or 1A output).

*
By measuring the secondary current, the primary current value can be accurately calculated.

Key Advantages

Compared to solid-core CTs, split-core CTs offer distinct benefits:

ADVANTAGE
DESCRIPTION

Live-line Installation
Can be installed on energized circuits without downtime or production loss.

Flexibility & Convenience
Ideal for retrofits or temporary monitoring; no need to replace cables or equipment.

Safety & Reliability
Reduces electrical hazards during installation, especially in high-voltage or critical power scenarios.

Wide Applicability
Suitable for power distribution systems, industrial equipment, Energy Management System [https://www.acrel-electric.ph/energy-management-system-1/]s (EMS), and smart grid monitoring.

Typical Applications

*
Energy Management & Monitoring

*
Real-time monitoring of electrical loads in factories and buildings to support energy-saving initiatives.

*
Power Distribution System Retrofits

*
Upgrading existing distribution panels for current monitoring without rewiring.

*
Fault Diagnosis & Prevention

*
Detecting current imbalances, harmonics, or overloads to prevent potential failures.

*
Renewable Energy Systems

*
Monitoring output currents from solar PV arrays or wind turbines.

Image: https://ecdn6.globalso.com/upload/p/653/image_other/2025-11/application-1-15.png

Image: https://ecdn6.globalso.com/upload/p/653/image_other/2024-06/application-2.png

Key Technical Parameters for Selection

Consider the following when selecting a split-core CT:

*
Rated Primary Current: Choose based on maximum load current (e.g., 200A, 500A, 1000A).

*
Accuracy Class: Common classes: 0.5, 1. Higher accuracy (e.g., 0.5) is required for energy audits.

*
Core Opening Size: Must exceed the outer diameter of the cable or busbar being measured.

*
Output Signal: Standard 5A/1A analog.

*
Protection Rating: For outdoor use, select IP65 or higher for dust and water resistance.
