What are the working processes of a green sand molding machine?

The working process of a green sand molding machine [https://www.junengmachinery.com/products/] mainly includes the following steps, combined with the sand molding technology in casting processes:

1Sand Preparation

Use new or recycled sand as the base material, adding binders (such as clay, resin, etc.) and curing agents in specific proportions. For example, in resin sand processes, recycled sand requires 1-2% resin and 55-65% curing agent, while new sand needs 2-3% resin.Control sand performance parameters, including strength (6-8 kg-f), moisture content ( less than or equal to 25%), and clay content ( less than or equal to 1%).

2Mold Preparation

Inspect the mold (pattern or core box) for flatness, movable blocks, and locating pins. Apply mold release agent to ensure smooth demolding.Install auxiliary components such as gating systems and chills, and clean them of rust or sand adhesion.

3Sand Filling and Compaction

Pour the mixed sand into the flask or core box, discarding the initial batch to ensure uniform curing.Compact the sand mechanically or manually to eliminate loose areas, then level the surface.

4Venting

Use venting needles to create air vents in the sand mold. The depth of vents in the upper mold should be 30-40 mm from the mold surface, while the lower mold requires 50-70 mm to prevent molten metal leakage.

5Mold Assembly and Pouring

Combine the upper and lower molds to form a complete casting cavity.Pour molten metal, which solidifies into the rough casting after cooling.

6Post-Treatment

Remove sand from the casting, clean the workpiece, and perform heat treatment or inspection.

The workflow of a green sand molding machine is similar to manual molding but improves efficiency and consistency through mechanization, making it suitable for mass production. Specific process parameters (such as sand temperature and resin dosage) must be adjusted based on production conditions.

Image: https://www.junengmachinery.com/uploads/junengCompany1.jpg [https://www.junengmachinery.com/products/]

Quanzhou Juneng Machinery Co.,Ltd. is a subsidiary of Shengda Machinery Co.,Ltd. specializing in casting equipment.A high-tech R&D enterprise that has long been engaged in the development and production of casting equipment, automatic molding machines,and casting assembly lines.
