Common Types of Fittings and Their Applications

Fittings play a crucial role in various piping and pneumatic systems, ensuring the sealing, stability, and durability of pipe connections. Different types of fittings are suitable for different piping connection needs. In this article, we will introduce several common fitting types to help you understand their functions and application scenarios.

1. Push-In Fittings

Push-in fittings are highly practical connectors widely used in pneumatic piping systems. The key feature of these fittings is that they allow for quick and tool-free connection or disconnection of pipes. With a simple "plug-and-play" design, they can rapidly restore equipment to normal operation. These fittings are known for their ease of installation, space-saving design, and high efficiency, making them ideal for environments that require fast and reliable connections.

2. Push-Lock Fittings

Push-lock fittings are primarily used for connecting devices such as cylinders and are suitable for pipes made of materials like PU, PE, nylon, and explosion-proof air hoses. These fittings offer strong sealing capabilities and secure pipe connections. When selecting push-lock fittings, it is important to match the internal diameter, external diameter, and wall thickness of the pipe. Materials commonly used include stainless steel and brass, ensuring durability and stability.

3. Barbed Fittings

Barbed fittings are typically used for soft hose connections. The key considerations when selecting barbed fittings are the inner diameter of the pipe and thread size. These fittings are generally used for straight-through connections and offer excellent sealing performance and stability, making them ideal for fluid and gas transfer systems.

4. C-Type Self-Locking Quick Fittings

C-type self-locking quick fittings are designed for situations where quick insertion and removal of air pipelines are needed. The male end automatically seals when inserted into the female end, and the female end automatically closes the air flow when the male end is removed. This self-locking mechanism ensures safety and sealing, making these fittings perfect for applications requiring frequent disconnections and maintenance.

5. Compression Fittings

Compression fittings consist of three parts: the fitting body, compression sleeve, and nut. These fittings offer strong sealing capabilities and high pressure resistance. They are easy to install and maintain, and they are widely used in industries such as chemicals, oil, and pneumatics. The fittings do not require welding and can be reused, making them ideal for high-strength connections.

6. Flared Fittings

Flared fittings share similar advantages with compression fittings, such as high pressure resistance and ease of installation. They are compact, lightweight, and offer excellent vibration resistance. These fittings are ideal for applications where space and weight are critical, and high-strength connections are required.

7. Clamped Fittings

Clamped fittings use the deformation of a clamp ring to create a seal and are primarily used for connecting hard pipes. Since these fittings cannot be reused, it is essential to ensure the seal is tight and stable during installation to avoid air or fluid leakage in the future.

Conclusion

Each type of fitting has its own unique advantages, and choosing the right one can significantly improve the overall performance of your piping system while ensuring the safety and stability of your equipment. Whether in pneumatic systems, fluid transfer, or industrial piping, understanding the characteristics and application scenarios of various fittings is key to efficient system management.

Contact Us: If you need more assistance with selecting and applying fittings, feel free to contact our expert team. We are here to provide you with professional technical support and solutions.
