STMicroelectronics TS942IN: Unleashing the Power of Precision Op-Amps for Battery-Powered Systems

The TS94x op-amps are ideal for battery-powered systems, where very low supply current and output rail-to-rail are required. Their very low - 1 pA typical input bias current and constant supply current oversupply voltage enhance the devices' performance near the end of the battery charge or battery life.

STMicroelectronics TS942IN's [https://www.sic-components.com/product/product?product_id=1040396] Features

* Rail-to-rail output voltage swing
* Micropower consumption (1.2 A)
* Single supply operation (2.5 V to 10 V)
* CMOS inputs
* Ultra-low input bias current (1 pA)
* ESD protection (2 kV)
* Latch-up immunity (class A)
* Available in SOT23-5 micro package

STMicroelectronics TS942IN's Applications

* Battery-powered systems (alarm)
* Portable communication systems (pagers)
* Smoke/gas/fire detectors
* Instrumentation and sensing
* PH meter

STMicroelectronics TS942IN's Attributes

TYPE
DESCRIPTION

Category
Integrated Circuits (ICs)LinearAmplifiersInstrumentation, Op Amps, Buffer Amps

Mfr
STMicroelectronics

Packaging
Tube

Part Status
Obsolete

Amplifier Type
General Purpose

Number of Circuits
2

Output Type
Rail-to-Rail

Slew Rate
0.0045V/s

Gain Bandwidth Product
10 kHz

Current - Input Bias
1 pA

Voltage - Input Offset
10 mV

Current - Supply
1.2A (x2 Channels)

Current - Output / Channel
5 mA

Voltage - Supply Span (Min)
2.5 V

Voltage - Supply Span (Max)
10 V

Operating Temperature
-40 degrees C ~ 85 degrees C

Mounting Type
Through Hole

Package / Case
8-DIP (0.300", 7.62mm)

Supplier Device Package
8-Mini DIP

Base Product Number

TS942

STMicroelectronics TS942IN's Category - Amplifiers

Operational amplifiers are a type of high-gain electronic component widely used in analog circuits. They possess the characteristics of high input impedance and low output impedance and are typically used in circuits such as signal amplification, filtering, integration, and differentiation. Common types of power amplifier chips include:

* BJT (Bipolar Junction Transistor) Power Amplifier Chips: Using bipolar junction transistors as the key components of the amplifier, they have relatively high power amplification capabilities and a wide frequency range.
* MOSFET (Metal-Oxide-Semiconductor Field-Effect Transistor) Power Amplifier Chips: Employing MOSFETs as the key components of the amplifier, they feature low power consumption, high efficiency, and good linear characteristics.
* GaAs (Gallium Arsenide) Power Amplifier Chips: Power amplifier chips manufactured using gallium arsenide materials, which have the characteristics of high frequency, high power, and low noise, and are commonly used in radio frequency and microwave applications.
* CMOS (Complementary Metal-Oxide-Semiconductor) Power Amplifier Chips: Power amplifier chips fabricated using CMOS technology, which possesses low power consumption, low cost, and good integration.
* Class-D (D-Class) Power Amplifier Chips: Achieving high-efficiency power amplification using PWM (Pulse Width Modulation) technology, commonly used in audio amplifiers and audio systems.
* Class-AB (AB-Class) Power Amplifier Chips: Combining the characteristics of Class-A and Class-B, they have both relatively high linearity and relatively high efficiency and are commonly used in audio amplifiers and communication systems.

TS942IN's MAnufacturer - STMicroelectronics

STMicroelectronics [https://www.sic-components.com/product/product?product_id=1040396] is a global independent semiconductor company and is a leader in developing and delivering semiconductor solutions across the spectrum of microelectronics applications. An unrivaled combination of silicon and system expertise, manufacturing strength, Intellectual Property (IP) portfolio, and strategic partners positions the Company at the forefront of System-on-Chip (SoC) technology and its products play a key role in enabling today's convergence trends.
