3D X-Ray Inspection System now with integrated AOI Option for maximum Fault Detection

11-29-2012 10:44 PM CET | Industry, Real Estate & Construction

Press release from: GOEPEL electronics Ltd.

3D x-ray inspection system OptiCon X-Line 3D

3D x-ray inspection system OptiCon X-Line 3D

GOEPEL electronic introduced a revolutionary AOI option as integral part of its 3D x-ray inspection (AXI) system OptiCon X-Line 3D. The combination provides users the opportunity to significantly increase test coverage by means of optical test technologies.

In contrast to other vendors’ combined inspection systems (AOI/AXI) solder joint inspection with OptiCon X-Line 3D is not only applied for hidden but all solder joints on electronic assemblies. This guarantees an ideal solder joint inspection avoiding AOI-specific reflections and shadows close to IPC-A610 specifications. Hence, soldering defects, hard to detect via AOI, can be safely found.

In the OptiCon X-Line 3D, AOI technology is utilised for all inspection tasks impossible to execute through AXI, such as polarity check, character and colour recognition as well as data matrix and barcode reading. These are explored by an AOI module, well-proven in GOEPEL electronic’s OptiCon AOI system series.

The intelligent combination of x-ray and optical inspection guarantees a nearly 100% visual test coverage“, says Andreas Tuerk, Team Manager for GOEPEL electronic’s AXI System Division. “As much x-ray inspection as possible and complementary AOI as necessary means an optimization of the entire inspection process. In addition, it provides an enormously fast optical test of the entire PCB.”

GOEPEL electronic is a worldwide leading vendor of professional JTAG/Boundary Scan solutions and technology innovator of IP based instrumentation. With more than 100 product launches the company became the biggest innovator in the market within the last five years. A network of branch offices, distributors and service partners ensures the global availability of the products as well as the support of the more than 7,000 system installations.
Founded 1991 and headquartered in Jena, Germany, GOEPEL electronic employs currently about 200 employees. GOEPEL electronic has continuously been ISO9001 certified since 1996 and has been honoured with TOP-JOB and TOP-100 awards for being one of the best medium-sized companies in Germany. GOEPEL electronic’s products won several awards in recent years and are used by the leading companies in telecommunication, automotive, space and avionics, industrial controls, medical technology, and other industries.
Further information about the company and its products can be found on the internet at www.goepel.com.

GOEPEL electronics Ltd.
Unit 1A
The Old Granary
Westwick, Cambridge
CB24 3AR/UK

Phone +44-1223-858298
Fax +44-1223-257800
www.goepel.co.uk

Stefan Meissner
press@goepel.com
