Huebner Giessen advances magnetic encoder technology

02-10-2012 06:53 AM CET | Industry, Real Estate & Construction

Press release from: Johannes Hübner Fabrik elektrischer Maschinen GmbH

/ PR Agency: Wassenberg Public Relations für Industrie & Technologie GmbH
Magnetic encoder system MAG-G with split pulse wheel and scanning head

Magnetic encoder system MAG-G with split pulse wheel and scanning head

The new magnetic encoders MAG(-G) 50…1200 from Johannes Huebner GmbH can be installed without bearings or housing. The system is resistant to shocks and vibrations and transmits interference-free signals even under extreme conditions. It adds an alternative to the standard optical scanning principle, which has to be protected in a closed housing with a bearing-supported shaft.

The magnetic scanning principle of Johannes Huebner GmbH uses a stationary sensor that records magnetic field changes of a rotating pulse wheel with north-south poles. The alternating magnetic field produces a sinusoidal or rectangular voltage in this sensor. And the magnetic scanning principle boasts additional benefits: It is resistant to soiling and provides for large radial and axial tolerances. Huebner magnetic encoders are wear-free and low noise. The variant with a split pulse wheel is particularly well suited for retrofitting and upgrading activities as well as for applications without a free shaft end.

Magnetic encoders: Applications and developments
Magnetic encoder technology is used in steel mills, ship drives, gas and water turbines, pumped storage power stations, large excavators in opencast mining, conveyors and drilling rigs, among others. Adjustments can be made to meet the individual customer’s requirements. Frank Tscherney, member of the board at Huebner: “Our complete service offering ranges from taking on-site measurements, analysing the installation position and designing the appropriate magnetic encoder system through to production, delivery and on-site assembly. We provide just the services our customer needs.”

Magnetic encoders by Johannes Huebner GmbH can even be installed in highly confined spaces due to their very slim design. For shaft diameters between 16 mm and 1,000 mm, the system adapts flexibly to the specific set-up of the customer’s application. Various options for attaching the pulse wheel are available depending on the actual design conditions, including screw mounting and hot shrink fitting as well as mounting by means of clamping pieces, clamping plates or tolerance sleeves. Magnetic encoder systems from Johannes Huebner can output various types of electrical signals: sinusoidal, incremental and absolute signals (SSI, EtherCat, other bus interfaces).
Further information is available at www.huebner-giessen.com

About Johannes Huebner Fabrik elektrischer Maschinen GmbH
No matter if steel or rolling mills, mining, container cranes, railway technology, hydroelectric power plants, wind turbine generators or power systems: Johannes Huebner GmbH, based in the Hessian town of Giessen, Germany, is considered the leading innovator in the field of measurement, encoder and drive technology. In more than 70 years the company has installed several thousand applications in heavy industry. Huebner Giessen offers an all-round complete service from determining on-site installation conditions through to installing the complete encoder systems. The company presently employs 85 staff.
