New Boundary Scan hardware from GOEPEL electronic compatible with MAC Panel SCOUT

01-26-2012 07:41 AM CET | Industry, Real Estate & Construction

Press release from: GOEPEL electronics Ltd.

SFX/PXI1149/Cx-FXT

SFX/PXI1149/Cx-FXT

GOEPEL electronic introduced PXI 1149/DAK, a mass interconnect interface within the frame of the technologically leading JTAG/Boundary Scan hardware platform SCANFLEX®. The new option for the SFX/PXI1149/Cx-FXT controller are compatible with SCOUT, the mass interconnect system from MAC Panel. Using this option, the customer can now easily combine JTAG/Boundary Scan with the PXI connectivity solution from MAC Panel.

“Simple wiring and excellent signal integrity are two of the most important task for test system builders”, says Alexander Beck, GOEPEL electronic’s integration expert. “Both challenges can be handled by the combination of the MAC Panel SCOUT system and the new hardware solution from GOEPEL electronic. At the same time, we extend the leading position of our unique hardware platform SCANFLEX.”

The new module is available in two versions. As option for the SFX/PXI1149/Cx-FXT and SFX/PXIe1149/Cx-FXT controller the PXI 1149/DAK2 has a differential test bus with 200 pin receiver and single-ended PIP resources. By contrast the PXI 1149/DAK1 has a single-ended test bus with 96 pin receiver as well as single-ended PIP resources and is an option for the SFX/PXI1149/Cx-FXT and SFX/PXIe1149/Cx-FXT controller. Both mass interconnect interfaces are also available as a variant supporting Direct Access Kit-Extended version, PXI 1149/DAK-E1 and PXI 1149/DAK-E2.

The new PXI 1149/DAK is fully supported by the industrially leading JTAG/Boundary Scan software platform SYSTEM CASCON™. SYSTEM CASCON™ is GOEPEL electronic’s professional JTAG/Boundary Scan development environment providing currently 45 completely integrated ISP, test, and debug tools.

About GOEPEL electronic:
GOEPEL electronic is a worldwide leading vendor of professional JTAG/Boundary Scan solutions and technology innovator of IP based instrumentation. With more than 100 product launches the company became the biggest innovator in the market within the last five years. A network of branch offices, distributors and service partners ensures the global availability of the products as well as the support of the more than 7,000 system installations. Founded 1991 and headquartered in Jena, Germany, GOEPEL electronic employs currently about 180 employees and generated a revenue of more than 22 Million Euro in 2010 (ca. $31Mio). GOEPEL electronic has continuously been ISO9001 certified since 1996 and has been honoured with TOP-JOB and TOP-100 awards for being one of the best medium-sized companies in Germany. GOEPEL electronic’s products won several awards in recent years and are used by the leading companies in telecommunication, automotive, space and avionics, industrial controls, medical technology, and other industries. Further information about the company and its products can be found on the internet at www.goepel.com.

GOEPEL electronics Ltd.
Unit 1A
The Old Granary
Westwick, Cambridge
CB24 3AR/UK

Phone +44-1223-858298
Fax +44-1223-257800
www.goepel.co.uk

Stefan Meissner
press@goepel.com
